Description of Arduino Nano
Overview
VL53L1X V2 is a high-performance Time-of-Flight (ToF) laser ranging sensor from STMicroelectronics.
It offers accurate distance measurement up to 4 meters, even in challenging lighting. Perfect for robotics,
drones, gesture recognition, and smart automation systems.
Key features
- Long-range measurement up to 4 meters
- ±25mm accurate Time-of-Flight laser sensing
- Low-power operation, ideal for IoT and battery devices
- Wide Field of View for multi-object detection
- Excellent performance in various lighting conditions
- I²C interface for easy integration with Arduino, STM32, ESP32, Raspberry Pi
Technical Specifications
| Parameter | Description |
|---|---|
| Model | VL53L1X V2 |
| Sensor Type | Time-of-Flight (ToF) Laser |
| Supply Voltage | 2.6V – 3.5V (typ. 3.3V) |
| Current Consumption | ~20mA (typical) |
| Measuring Range | 40mm – 4000mm |
| Accuracy | ±25mm |
| Interface | I²C (up to 400kHz) |
| Field of View (FoV) | ~27° |
| Sensor Size | ~4.9mm × 2.5mm |
| Module PCB | Breakout Board |
| Country of Origin | China |
Package Content
- VL53L1X V2 Laser Distance Sensor Module
What is VL53L1X V2 Sensor?
It is a Time-of-Flight (ToF) laser distance measuring sensor that calculates distance
using the time taken by light to reflect from a target. Very accurate and stable for smart sensing solutions.
How VL53L1X Works?
The sensor emits low-power laser pulses and measures the round-trip time to detect distance.
It communicates via I²C, making it easy to integrate with microcontrollers for real-time distance data.
Usage/Application
Perfect for:
- Drone obstacle avoidance & altitude hold
- Robotics navigation & mapping
- Gesture & motion detection
- IoT proximity sensing
- Smart automation devices
Warranty & Return Policy
Note: This item cannot be returned, but if it arrives damaged or doesn’t work properly,
please contact us for assistance or resolution. Please make a video before opening the box.
Need Assistance ?
Please call to our office to get more information about products, delivery information, warranty or return policy.
Mobile: +8801641757175
Email: [email protected]
FAQs About VL53L1X V2 Sensor
Q1: What is the maximum measuring range?
Up to 4 meters.
Q2: Does it work in bright light?
Yes, optimized for strong ambient lighting.
Q3: Can I use it with Arduino/ESP32/Raspberry Pi?
Yes, supports I²C communication.
Q4: Does it support gesture recognition?
Yes, wide FoV enables multi-object sensing.
Q5: Is calibration needed?
Basic factory calibration included; optional custom tuning for accuracy.
